M10 小型軸流式風扇
型號 :
M10 , M10D
| 型號 Model / 規格 Spec. |
電壓 Voltage V |
頻率 Frequency Hz |
相數 Phase ⌀ |
極數 Poles P |
入力 Input Power W |
電流 Current A |
轉速 Speed RPM |
風量 Max Air Flow CMM |
靜壓 Max Pressure mmAq |
噪音 Noise dB(A) |
淨重 Net Weight Kg |
| JAF-M10 | 115 | 60 | 1 | 4 | 58 | 0.56 | 1670 | 18.7 | 14 | 59 | 3.2 |
| 230 | 50 | 1 | 4 | 54 | 0.30 | 1420 | 15.5 | 11 | 55 | 3.2 | |
| 60 | 58 | 0.28 | 1670 | 18.7 | 14 | 59 | |||||
| JAF-M10D | 220 | 50 | 3 | 4 | 33 | 0.20 | 1420 | 15.5 | 10.5 | 55.0 | 3.2 |
| 60 | 37 | 0.17 | 1640 | 18.5 | 13 | 58.5 | |||||
| 380 | 50 | 3 | 4 | 33 | 0.12 | 1420 | 15.5 | 10.5 | 55.0 | 3.2 | |
| 60 | 37 | 0.11 | 1640 | 18.5 | 13 | 58.5 |
