M14 小型軸流式風扇
型號 :
M14 , M14D
| 型號 Model / 規格 Spec. |
電壓 Voltage V |
頻率 Frequency Hz |
相數 Phase ⌀ |
極數 Poles P |
入力 Input Power W |
電流 Current A |
轉速 Speed RPM |
風量 Max Air Flow CMM |
靜壓 Max Pressure mmAq |
噪音 Noise dB(A) |
淨重 Net Weight Kg |
| JAF-M14 | 115 | 60 | 1 | 4 | 120 | 1.2 | 1500 | 46 | 10.0 | 67.5 | 8.0 |
| 230 | 50 | 1 | 4 | 90 | 0.5 | 1350 | 42 | 12.8 | 63.5 | 8.0 | |
| 60 | 125 | 0.6 | 1500 | 46 | 10.0 | 67.5 | |||||
| JAF-M14D | 220 | 50 | 3 | 4 | 85 | 0.4 | 1350 | 42 | 14 | 63.5 | 8.0 |
| 60 | 120 | 0.42 | 1500 | 46 | 15 | 67.5 | |||||
| 380 | 50 | 3 | 4 | 85 | 0.23 | 1350 | 42 | 14 | 63.5 | 8.0 | |
| 60 | 120 | 0.25 | 1500 | 46 | 15 | 67.5 |
