10" 風扇
AC FAN SK254AP
254x89mm (10”x3.5”) 470~685CFM
254x89mm (10”x3.5”) 470~685CFM
型號 :
SK254
| 馬達 | Motor | Single phase induction capacitor motor, thermally protected |
| 外殼 | Housing/Frame | Die-cast aluminum, Painted black (AP) or Plated (AN) |
| 風葉 | Impeller | PC thermoplastic + glass fiber, UL 94V-O |
| 軸承 | Bearing Type | Two-ball bearing |
| 接電方式 | Connection | T-terminal push-on type or W-lead wire type |
| 耐壓 | Dielectric Strength | 1 min. at 1,500VAC, 50/60Hz |
| 溫度範圍 | Operating Temp | Recommended ambient range -20°C~+70°C |
| 壽命 | Life Expectancy | 60,000 hours at 40°C |
| 淨重 | Net Weight | 2 kg (4.4 pounds) |
| 認證 | Safety Approvals | UL, CUL, TUV, CE, RoHS |
| Model No. | Rated VAC | Freq. Hz | Rated Input Amp | Rated Input watt | Rated Speed RPM | Max. Air Flow | Max. Static Pressure | Noise Level (dB) | ||
| m3/min | CFM | mm-H20 | inch-H20 | |||||||
| 型號 | 電壓 | 頻率 | 電流 | 功率 | 轉速 | 最大風量 | 最大風壓 | 噪音 | ||
| SK245AP-11-1 | 110 (100V-120V) | 50/60 | 0.55/0.62 | 60/67 | 2100/1800 | 194/17.1 | 685/605 | 8.6/7.1 | 0.34/0.28 | 61/58 |
| SK245AP-11-2 | 110 (100V-120V) | 50/60 | 0.22/0.24 | 34/37 | 1400/1600 | 13.3/15.5 | 470/546 | 7.0/8.6 | 0.28/0.34 | 54/56 |
| SK245AP-22-1 | 220 (200V-240V) | 50/60 | 0.26/0.3 | 60/67 | 2100/1800 | 194/17.1 | 685/605 | 8.6/7.1 | 0.34/0.28 | 61/58 |
| SK245AP-22-2 | 220 (200V-240V) | 50/60 | 0.16/0.14 | 34/37 | 1400/1600 | 13.3/15.5 | 470/546 | 7.0/8.6 | 0.28/0.34 | 54/56 |
Customised item: Double Voltage, FB, RD
