M16 小型軸流式風扇
型號 :
M16 , M16D
| 型號 Model / 規格 Spec. |
電壓 Voltage V |
頻率 Frequency Hz |
相數 Phase ⌀ |
極數 Poles P |
入力 Input Power W |
電流 Current A |
轉速 Speed RPM |
風量 Max Air Flow CMM |
靜壓 Max Pressure mmAq |
噪音 Noise dB(A) |
淨重 Net Weight Kg |
| JAF-M16 | 220 | 50 | 1 | 4 | 170 | 0.9 | 1350 | 52 | 23 | 68.7 | 9.0 |
| 60 | 240 | 1.2 | 1540 | 56 | 26 | 68.2 | 9.0 | ||||
| JAF-M16D | 220 | 50 | 3 | 4 | 160 | 0.75 | 1350 | 52 | 23 | 65.8 | 9.0 |
| 60 | 220 | 0.82 | 1500 | 56 | 26 | 68.7 | |||||
| 380 | 50 | 3 | 4 | 160 | 0.47 | 1350 | 52 | 23 | 65.8 | 9.0 | |
| 60 | 220 | 0.42 | 1500 | 56 | 26 | 68.7 |
