M12 小型軸流式風扇
型號 :
M12 , M12D
| 型號 Model / 規格 Spec. |
電壓 Voltage V |
頻率 Frequency Hz |
相數 Phase ⌀ |
極數 Poles P |
入力 Input Power W |
電流 Current A |
轉速 Speed RPM |
風量 Max Air Flow CMM |
靜壓 Max Pressure mmAq |
噪音 Noise dB(A) |
淨重 Net Weight Kg |
| JAF-M12 | 115 | 60 | 1 | 4 | 75 | 0.75 | 1560 | 31 | 13.0 | 63.8 | 7.2 |
| 230 | 50 | 1 | 4 | 60 | 0.30 | 1380 | 27 | 13.5 | 60.2 | 7.2 | |
| 60 | 80 | 0.40 | 1560 | 31 | 13.0 | 63.8 | |||||
| JAF-M12D | 220 | 50 | 3 | 4 | 60 | 0.30 | 1350 | 27 | 13 | 59.4 | 7.2 |
| 60 | 75 | 0.30 | 1500 | 30 | 14 | 62.3 | |||||
| 380 | 50 | 3 | 4 | 60 | 0.17 | 1350 | 27 | 13 | 59.4 | 7.2 | |
| 60 | 75 | 0.17 | 1500 | 30 | 14 | 62.3 |
